1st M. 2 highest PCI Express generation: 4.0
1st M. 2 largest key size: 2280
2nd M. 2 highest PCI Express generation: 4.0
2nd M. 2 largest key size: 2280
ACPI version: 5.0
Antenna included: Yes
ATX Power connector (24-pin): Yes
Audio Chip: Realtek ALC897
Audio output channels: 7.1 channels
Batteries included: Yes
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Battery weight: 3 g
BIOS memory size: 128 Mbit
BIOS type: UEFI AMI
Bluetooth: Nu
Bluetooth version: 5.3
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Canale audio: 7.1
Chipset audio integrat: Realtek
Clear CMOS jumper: Yes
Component for: PC
Country of origin: China
CPU fan connector: Yes
Depth: 244 mm
Desktop Management Interface (DMI) version: 2.7
DirectX version: 12.0
DisplayPort version: 1.2
DisplayPorts quantity: 1
DVI-D ports quantity: 0
ECC сompatibility: ECC & Non-ECC
EPS power connector (8-pin): Yes
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 1
Format: Micro-ATX (mATX)
Front panel audio connector: Yes
Front panel connector: Yes
Gaming: Da
HDCP: Yes
HDMI: Da
HDMI ports quantity: 1
HDMI version: 2.1
Headphone outputs: 1
Height: 35 mm
LAN controller: Realtek RTL8111H
Line-in: Yes
Lithium weight per battery: 0.07 g
Maximum internal memory: 128 GB
Maximum internal memory per slot: 32 GB
Maximum internal memory supported by processor: 128 GB
Maximum resolution: 4096 x 2304 pixels
Memorie maxima: 128 GB
Memory channels: Dual-channel
Memory slots type: DIMM
Model Chipset: B760
Motherboard chipset: Intel B760
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Numar sloturi memorie: 4
Number of battery cells: 1
Number of chassis fan connectors: 3
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of HDDs supported: 4
Number of M. 2 (M) slots: 2
Number of memory slots: 4
Number of RGB LED pin headers: 2
Number of SATA III connectors: 4
Number of storage drives supported: 6
Onboard-CPU: No
Package depth: 268 mm
Package height: 68 mm
Package weight: 1.2 kg
Package width: 270 mm
Parallel connector: Yes
Parallel processing technology support: Not supported
PC health monitoring: Fan, Temperature, Voltage, Water cooling
PCI: 0
PCI Express x1 (Gen 3. x) slots: 2
PCI Express x16 (Gen 4. x) slots: 1
Power source type: ATX
Processor manufacturer: Intel
Processor socket: LGA 1700
Product colour: Grey
Products per shipping (inner) case: 1 pc(s)
PS/2 ports quantity: 1
RAID levels: 0, 1, 5, 10
RAID support: Yes
RGB LED pin header: Yes
RJ-45 LAN: 1
S/PDIF out connector: Yes
Screws included: Yes
Serial port headers: 1
Serial-or-Paralel: No/No
Sloturi M. 2: 2
Soclu Procesor: Socket 1700
Supported memory clock speed (max): 5333 MHz
Supported memory types: DDR4-SDRAM
Supported processor sockets: LGA 1700
Supported storage drive interfaces: M. 2, SATA III
Supported storage drive types: HDD & SSD
System Management BIOS (SMBIOS) version: 2.7
Thunderbolt: Nu
Tip Memorie: DDR4
Tip slot interfata grafica: PCIe 4.0 x16
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
TPM connector: Yes
Unbuffered memory: Yes
USB 2.0 connectors: 2
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB Type C: Nu
VGA (D-Sub) ports quantity: 0
Video-Connection: HDMI/DP
Warranty period: 3 year(s)
Weight: 1.1 kg
Wi-Fi: Yes
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Width: 244 mm
WiFi-AP antenna jack: 2
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Wireless: Da
WLAN controller model: Realtek RTL8851BE
