10G support: No
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Broadcast storm control: Yes
Cables included: Power
Compliance certificates: CE, Federal Communications Commission (FCC), Industry Canada (IC), RoHS
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
DC input voltage: 5 V
Depth: 98 mm
Ethernet LAN data rates: 10,100, 1000 Mbit/s
Fanless: Yes
Forwarding rate: 7.4 Mpps
Heat dissipation: 9.62 BTU/h
Height: 25 mm
Housing material: Steel
IGMP snooping: Yes
Input current: 0.6 A
Jumbo frames: 16
Jumbo frames support: Yes
LAN-Port-Type: FastEthernet
LED indicators: Activity, Link, Power
Link aggregation: Yes
Loop protection: Yes
MAC address table: 2000 entries
Management: Nu
Montare in rack: Nu
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Number of queues: 4
Number of VLANs: 32
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Packet buffer memory: 1 MB
PoE: Nu
Port mirroring: Yes
Porturi RJ 45: 5× Gigabit RJ45 Ports
Porturi SFP: N/A
Power connector: DC-in jack
Power consumption (max): 2.82 W
Power over Ethernet (PoE): No
Power source: AC/DC
Power supply included: Yes
Product colour: Black
Quality of Service (QoS) support: Yes
Queue scheduling algorithms: Priority queuing (PQ)
Rack mounting: No
Rate limiting: Yes
Reset button: Yes
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Store-and-forward: Yes
Switch layer: L2
Switch type: Managed
Switching capacity: 10 Gbit/s
User guide: Yes
Virtual LAN features: Port-based VLAN, Tagged VLAN
Viteza transfer: Gigabit
Width: 100 mm
