• 100 W per canal (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch)
• 160 W per canal (4 ohms, 1 kHz, 0.9% THD, 1-ch)
• 160 W per canal (8 ohms, 1 kHz, 10% THD, 1-ch)
• Ofera posibilitatea de a adauga boxe wireless surround (MusicCast 20 sau MusicCast 50)
• Optimizarea sunetului YPAO
• Optimizarea sunetului R. S. C. Reflected Sound Control
• Compatibil Amazon Alexa
• Anti Resonance Technology (A. R. T. )
• Panou frontal din aluminiu
• Compatibil MusicCast
• Servicii de streaming incorporate
• HDMI® (7 in / 2 out) cu Dolby Vision si Hybrid Log-Gamma
• Intrare Phono

 Dolby Atmos, DTS:X si Cinema DSP : compatibilitatea cu aceste tehnologii audio va transforma o experienta ordinara intr-una extraordinara, cu un sunet surround realist, bine pozitionat in orice zona a camerei de Home Cinema.



  Optimizare profesionala a sunetului prin YPAO - RSC (Reflected Sound Control) : sistemul YPAO - RSC analizeaza prin intermediul microfonului inclus si al semnalului de test acustica camerei si masoara diversi parametri ai boxelor instalate, apoi modifica si calibreaza parametrii interni de amplificare pentru a se atinge un sunet optim din combinatia camera - boxe.

  Receiverele AV Yamaha folosesc amplificatoare discrete pentru a minimaliza distorsiunile si au alimentari dedicate diferite pentru sectiunile digitala si analogica, DAC-uri de inalta performanta pentru reproducerea muzicii inclusiv in High-Resolution, atentie este acordata fiecarui detaliu de proiectare pentru a asigura cel mai bun sunet posibil.

  Usurinta in instalarea boxelor Surround : puteti combina acest receiver cu boxe active wireless Yamaha MusicCast 50 sau MusicCast 20 pentru a configura boxe surround spate fara a mai folosi cabluri de boxe, prin intermediul aplicatiei Musicast.



O lume intreaga de muzica si servicii de streaming : explorati o infinitate de surse de muzica din internet radio si servicii de streaming online prin instalarea aplicatiei dedicate pe smartphone sau tableta pentru un control complet si usor.


Specificatii Tehnice:

 Amplifier SectionChannel7.2Rated Output Power (1kHz, 1ch driven)160 W (4 ohms, 0.9% tdD)Rated Output Power (20Hz-20kHz, 2ch driven)100 W (8 ohms, 0.06% tdD)Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)160 W (8 ohms, 10% tdD)Dynamic Power per Channel (8/6/4/2 ohms)130 / 170 / 195 / 240 WSurround Sound ProcessingCINEMA DSPYes (3D)DSP Programs17Dialog Level AdjustmentYesVirtual Presence SpeakerYesVirtual Surround Back SpeakerYesDialogue LiftYes (no presence speakers required)SILENT CINEMA / Virtual CINEMA DSPYes (Virtual CINEMA FRONT)Dolby AtmosYesDolby TrueHDYesDolby Digital PlusYesDolby SurroundYesDTS:XYesDTS-HD Master AudioYesFile FormatMP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHzPure DirectYes (witd video on mode)Compressed Music EnhancerYes (incl. enhancer for Bluetootd®)YPAO multi-point measurementYes (R. S. C)YPAO VolumeYesAdaptive DRC (Dynamic Range Control)YesInitial Volume & Maximum Volume SettingYesA. R. T. WedgeYesBi-amp capabilityYesAudio DelayYes (0-500 ms)DA ConverterBurr-Brown 384 kHz / 32-bit DAC x 4 for main zoneVideo Features4K Ultra HD Pass-tdrough and upscalingYes (4K / 60p, 4:4:4)HDMI 3D passtdroughYesHDMI eARCYes (via future firmware update)HDMI Audio Return ChannelYesHDMI upscalingYes (Analogue to HDM® / HDMI to HDMI)Deep Color/x. v. Color/24Hz Refresh Rate /Auto Lip-SyncYesConnectivityMusicCast SurroundYesHDMI Input/Output7 / 2 (HDCP2.2, HDR10 / Dolby Vision / HLG and BT. 2020 compatible)HDMI CECYes (SCENE, Device Control)USB InputUSB Memory, Portable Audio PlayerNetwork PortYesWi-FiYes (2.4 / 5 GHz)AirPlayYesBluetootdYes (SBC / AAC)Front AV InputUSB / Mini JackDigital Audio Input/Output: Optical2 / 0Digital Audio Input/Output: Coaxial2 / 0Analog Audio Input/Output5 (front 1) / 0Phono InputYesComponent Video Input/Output1 / 0Composite Video Input/Output1 / 0Preout7.2-chHeadphone Output1Tuner SectionFM/AM TunerYes (FM only)DAB TunerYes (Availability varies by region. )User InterfaceOn-screen displayGraphical User Inter faceSCENESCENE (8 sets)App ControlYes (iPhone / iPad / Android phone / tablet)Web Browser ControlYesRemote Control UnitYesZone ControlZone 2 Audio OutputLine outputPowered ZoneZone 2Zone B OutputYes (HDMI)RS-232C InterfaceYes+12V Trigger Output1Remote (IR) Input/Output1 / 1Party ModeYesGeneralStandby Power Consumption (IR only)≤0.1WAuto Power StandbyYesECO modeYesDimensions (W x H x D)435 x 171 x 382 mm (witd antenna: 435 x 248 x 382 mm); 17-1/8 x 6-3/4 x 15 (witd antenna: 17-1/8 x 9-3/4 x 15)Weight11.0 kg; 24.3 lbs.


Denumiri similare la Amplificator Yamaha RX-A880: RX A 880, RXA880, RX A880, RX-A 880
